Remote Speaker Microphone (RSM01)
Remote Speaker Microphone
Robust, slim-line, lightweight traditional lapel worn speaker/microphone.
High quality audio reproduction with the option to fit an earphone via the 3.5mm socket.
Kevlar lined for added strength and longevity
Water resistant with a 8 way robust metal clothing clip and extremely durable coil cable.
A top of the range fist size remote speaker/mic.
Microphone Specifications:
Dimension: Ø9.7 x 6.5mm
Sensitivity: -40 ± 3db
Direction: Omnidirectional
Output Impedance: 2.2K Ω
Current Consumption: 500A
Working Voltage: 1.5V
Audio Response: 50Hz – 10KHz
Speaker Specifications:
Dimension: Ø36mm
Impedance: 8 Ω±15%
Output Sound Pressure Level: 80±3db
Power Rating: Normal .05W
Maximum 1W
Frequency Range: 280Hz-6KHz average
SPL-10db
Cable Specifications:
Cable Diameter: Ø3.8mm
Cable Length: 45cm – 1.5m
Colour: Black
Material: Thermoplastic polyurethanes
Optional Extras:
Receive only earpiece to be plugged into 3.5mm socket on the microphone
EH/SR /35 short
BEHR/01/45
EH/ACT/35 short
EH/BUD/35
Order Code: RSM01/xx Specify Connector required or Make & Model number of radio.
